Instructions for work
Mower conditioner
FC243
37
2. Adjustments in working position
Cutting height
The desired cutting height is obtained directly by
adjusting the top link length. The height can be adjusted
between 30 and 80 mm (1.1’’ - 3.1’’) depending on the
tractors.
To obtain a different cutting height:
- Place the machine in transport position.
- Lower the machine on the ground to remove weight
from the top link.
- Modify the top link length to alter the machine tilt
angle.
- Place the machine in working position to check cutting
height.
-
-
If the tractor is fitted with a hydraulic top link, the
machine tilt angle can be adjusted in working
position.
The maximum cutting height (L1 = 80 mm (3.1’’))
is obtained when the discs are parallel to the
ground.
The minimum cutting height must not be below
(L2 = 30 mm (1.1’’)).
Too low a cutting height can lead to:
Excessive disc and knife wear.
Crop being contaminated by soil.
Delay in regrowth.
