KN284DGB B
Read carefully before starting the machine
OPERATOR'S MANUAL
Mower conditioner
D0001 > E0000
FC3160TCD-3560TCD-4060TCD
KN284DGB B
- English - 02-2015

Table of Contents

Questions and Answers

  • M
    Mrs. Amanda WeaverSep 9, 2025
    Why is my KUHN Lawn Mower rotor finger rattling?
    • X
      Xavier JonesSep 9, 2025
      If your KUHN Lawn Mower's rotor fingers are rattling, it could be due to insufficient rotor speed. To resolve this, select the rabbit position to achieve a rotor speed of 1000 min-1. Another possible cause is that the conditioning hood is too closed; try positioning the rotor conditioning hood further away. Excessive ground speed can also contribute to this issue, so reducing your ground speed may help.
  • B
    Brian CoxAug 23, 2025
    What to do if soil build up in front of the cutterbar of KUHN Lawn Mower?
    • P
      pmayerAug 23, 2025
      If soil is building up in front of the cutterbar of your KUHN Lawn Mower, it could be due to too much cutterbar down pressure. Try adjusting the mowing unit ground pressure to reduce this. Also, very wet working conditions can contribute to this issue, so adjust both the mowing unit ground pressure and the cutting height.
  • E
    Elizabeth MendezAug 25, 2025
    Why is there uneven stubble with my KUHN FC3160TCD?
    • K
      Kevin DrakeAug 25, 2025
      Uneven stubble can occur due to several reasons. Check for dull or broken knives and replace them if necessary. Ensure knives are installed correctly, with the arrow on the knife's upper face pointing in the disc's direction of rotation. Reduce ground speed if it's excessive. Also, verify and adjust the cutting height and mowing unit floatation as needed. If dealing with tangled or down crops, reduce the cutting height and increase the mowing unit ground pressure.
  • J
    Joanna DiazAug 26, 2025
    What to do if soil builds up in front of the cutterbar on my KUHN FC3160TCD Farm Equipment?
    • D
      David BridgesAug 27, 2025
      If soil builds up in front of the cutterbar, it may be due to too much cutterbar down pressure. Adjust the mowing unit ground pressure to alleviate this. This issue may also arise in very wet working conditions, so consider adjusting both the mowing unit ground pressure and the cutting height.
  • J
    jacob48Aug 27, 2025
    What to do if my KUHN FC3160TCD requires too much pull power?
    • J
      Jody JonesAug 28, 2025
      If your machine requires too much pull power, the cutterbar down pressure might be too high. Adjust the mowing unit ground pressure to resolve this.
  • T
    Todd PorterAug 29, 2025
    What to do if I have badly shaped windrows with my KUHN FC3160TCD Farm Equipment?
    • B
      Brittney JacksonAug 29, 2025
      Badly shaped windrows can be caused by a PTO speed that is too low. Check the PTO speed, referring to the decal on the machine. Alternatively, the rotor speed might be too high; select the turtle position to obtain a rotor speed of 780 min-1. Finally, ensure that both swath shields are correctly adjusted.
  • R
    rrichSep 18, 2025
    What to do if the conditioning rotor is obstructed in my KUHN FC3160TCD Farm Equipment?
    • J
      Jessica CherrySep 18, 2025
      Obstruction of the conditioning rotor in KUHN Farm Equipment can occur due to insufficient rotor speed. Adjust the finger conditioning rotor speed to correct this. Also, check the PTO speed referring to the decal fitted on the machine, if it is too low. If the swath shields are too closed, open them.
  • S
    Susan StewartSep 18, 2025
    Why is there a rotor finger rattle in my KUHN FC3160TCD?
    • D
      Dr. Jordan FletcherSep 19, 2025
      A rotor finger rattle in KUHN Farm Equipment can be caused by insufficient rotor speed; select the rabbit position to obtain a rotor speed of 1000 min-1. If the conditioning hood is too closed, position the rotor conditioning hood further away. Excessive ground speed can also contribute; reduce ground speed.
  • C
    Charlotte HartSep 8, 2025
    How to fix uneven stubble with KUHN Lawn Mower?
    • M
      Melanie MorrisSep 8, 2025
      If your KUHN Lawn Mower leaves uneven stubble, several factors could be the cause. The knives might be dull or broken, in which case you should replace them. Also, ensure the knives are installed correctly with the arrow on the knife's upper face pointing in the disc's direction of rotation. Excessive ground speed, incorrect cutting height, or incorrect mowing unit floatation can also lead to this issue; reduce ground speed, adjust the cutting height, or adjust the mowing unit ground pressure accordingly. If you're dealing with tangled and down crops, try reducing the cutting height and increasing the mowing unit ground pressure.
  • G
    Gina SimmonsSep 4, 2025
    What to do if it's impossible to decrease or increase the mowing unit ground pressure sufficiently on my KUHN FC3160TCD?
    • M
      Michael BaxterSep 5, 2025
      If it's impossible to sufficiently decrease or increase the mowing unit ground pressure, it may be due to soil build-up on the machine and maximum ground pressure reduction. Adjust torsion bars of the ground pressure system. (See maintenance and storage chapter)

Summary

Dear Owner

Identification of the Machine

Machine Views and Identification Plate

Diagrams of front/rear views and information on the model identification plate.

Optional Equipment

List of optional equipment available for the mower conditioner.

Safety

Symbol and General Safety Instructions

Explanation of symbols and core safety guidelines for operating the machine.

Operation and Coupling Safety

Precautions for coupling, PTO shaft, hydraulics, driving, and general operation.

Maintenance and Repair Safety

Safety measures required during maintenance, repair, and troubleshooting.

Safety Decals and Road Transport

Location/description of safety decals and road transport safety equipment.

Road Safety Regulations

Information on road safety equipment and compliance with traffic regulations.

Machine Specifications

Component Description and Glossary

Overview of machine parts and definitions of technical terms.

Technical Specifications

Detailed technical data, dimensions, and performance specifications.

Required Equipment and Sound Levels

List of required equipment and measured sound levels during operation.

Putting into Service

Control Elements and Tools

Identification of control elements and supplied tools for machine setup.

Coupling and Uncoupling Procedures

Step-by-step guide for attaching and detaching the machine from the tractor.

PTO Shaft Installation and Adjustment

Instructions for installing and adjusting the primary and intermediate PTO shafts.

Machine Adjustments

Procedures for adjusting machine links, frame height, and check chains.

Instructions for Transport

Transport Position and Procedure

Guidelines for placing and securing the machine in transport configuration.

Road Regulation Compliance

Ensuring the machine complies with road transport laws and regulations.

Instructions for Work

Putting Machine into Work Position

Procedure to transition the machine from transport to its operational working state.

Working Position Adjustments

Adjustments for cutting height, ground pressure, rotor speed, and conditioning.

Swathing and Wide Spreading

Adjusting swath width and operating the wide spreading system.

Machine Use and Groundspeed

General operation guidelines and adapting forward speed to field conditions.

Recommendations for Uncoupling

Optional Equipment

Check Chains and Lifters

Description and purpose of optional check chains and lifters.

Swath Shields and Yoke

Details on optional swath shields and the 1 3/8 - 21 spline yoke.

Raised Skid Shoes and SMV Sign

Information on optional raised skid shoes and SMV signs for height adjustment and safety.

Maintenance and Storage

Maintenance Frequency Chart

Schedule for routine maintenance tasks based on usage hours or time.

Cleaning Procedures

Instructions for thorough cleaning of the mower conditioner.

Lubrication and Greasing

Detailed procedures for lubricating PTO shafts, joints, and greasing points.

Oil Draining and Refilling

Procedures for draining and refilling oil in cutterbars and gearboxes.

Knife and Securing Element Inspection

Procedures for inspecting and replacing knives and their fastening components.

Disc and Spring Plate Replacement

Instructions for replacing mower discs and spring plates.

Rotor Safety System Maintenance

Procedures for maintaining and replacing components of the rotor safety system.

Seasonal Storage Procedures

Tasks for storing the machine at the end and preparing it at the start of each season.

Troubleshooting Guide

Limited Warranty
