6. - Putting into service
FC3160TCD-3560TCD-4060TCD
43
KN284DGB B
Mower conditioner
6.2.9 Adjusting the machine
Lateral adjustment of the lower links.
Frame height and check chains
- Balance the play on either sides of the lift linkage
and lock lower link stabilizers.
- Lower tractor lift linkage until hitch pins are at a
distance (H) slightly over 650 mm (2’1.6’’) from
the ground.
