KUHN FC3160TCD - Putting the Machine into Transport Position

FC3160TCD-3560TCD-4060TCD
46
7. - Instructions for transport
KN284DGB B
Mower conditioner
7.2 Putting the machine into
transport position
From the working position:
- Activate mowing unit lift cylinders to fully raise the
machine.
- Operate drawbar shift cylinder to put the drawbar
in transport position.
- Shut-off drawbar shift cylinder lock valve (1).
- Shut-off mowing unit lift cylinder lock valves (2).
1
2
