11. - Maintenance and storage
FC3160TCD-3560TCD-4060TCD
87
KN284DGB B
Mower conditioner
11.4 Maintenance
11.4.1 Checking the oil levels
 Gyrodine gearbox
 Gearbox
- Check Gyrodine gearbox level:
• The "MAX" level corresponds to the mark on the
dipstick plug (A).
• The "MIN" level corresponds to the end of the
dipstick plug (B).
- Check gearbox oil level:
• The "MAX" level corresponds to the mark on the
dipstick plug (A).
• The "MIN" level corresponds to the end of the
dipstick plug (B).
