11. - Maintenance and storage
FC3160TCD-3560TCD-4060TCD
101
KN284DGB B
Mower conditioner
11.4.3 Fitting of the lifters
2 pairs of lifters are supplied with the machine.
In case of side ejections, lifters can be fitted on the
outer disks (See drawing below):
- FC3160TCD
- FC3560TCD
- FC4060TCD
- Repeat procedure on the second disk.
- Remove bolts and washers (1).
- Remove disc (2).
