FC3160TCD-3560TCD-4060TCD
100
11. - Maintenance and storage
KN284DGB B
Mower conditioner
 Spring plate replacement
Inner disc:
Intermediate discs:
- Remove the disc:
• See section: ’’Disc replacement’’.
- Refit the disc.
• See section: ’’Disc replacement’’.
The replacement of the inner disc spring
plate must be carried out by a Kuhn
authorized dealer.
- Remove spring plate (1).
- Fit a new spring plate.
