11. - Maintenance and storage
FC3160TCD-3560TCD-4060TCD
109
KN284DGB B
Mower conditioner
11.4.5 Rotor maintenance
Finger replacement
- FC3160TCD
- FC3560TCD
FC4060TCD
Immediately replace worn or damaged parts
with original manufacturer parts.
Respect mounting order.
Fit roll pins at 180° to each other with slots lined up
in the direction of the main load.
Respect the position of short and long
fingers to avoid interference with the cutter
bar.
