7. - Instructions for transport
FC3160TCD-3560TCD-4060TCD
47
KN284DGB B
Mower conditioner
The machine is in transport position.
Opened position (1).
Closed position (2).
- Release and lift side guard using 18mm box
spanner supplied with the machine.
- The side guard automatically locks in raised
position.
- Repeat procedure on the second side guard
Never engage the tractor PTO drive when the
machine is in transport position.
