FC3160TCD-3560TCD-4060TCD
96
11. - Maintenance and storage
KN284DGB B
Mower conditioner
Disc replacement
After replacing the last knife, check that the
tool has been removed and put away.
- Place a wooden wedge (1) between two discs to
stop them from moving.
- Remove the 4 bolts (2) and their conical washers.
- Remove disc cover (1).
- Remove the disc (2).
- Replace worn or damaged disk with a new disk.
