11. - Maintenance and storage
FC3160TCD-3560TCD-4060TCD
97
KN284DGB B
Mower conditioner
Reinstalling
- Refit the disc (2).
Respect disc direction of rotation according to fitting
of knives. Make sure the arrow on the knife upper
face is pointing in the disc's direction of rotation.
- Reinstall disc cover (1).
- Respect an X of 90° between neighboring discs.
- Reinstall bolts (1) and their conical washers.
