3.3 Connect Ethernet
The Ethernet 10/100 baseTX is to be connected to the front part of
the RJ45 connector. To do so, insert the corresponding plug until it
snaps in. The shield is connected to the hat rail. Please note that the
transmission rate adjusts itself automatically: the slowest rate on the
network determines the speed. For connection to an existing
network, connect the FNL onto the corresponding hub or switch via
patch cable. For direct connection without use of a hub or a switch, a
cross-wired Ethernet cable is required.
