Kunbus FNL Series User Manual

FNL
8 / 31
2.2 PROFIBUS DP
FNL supports PROFIBUS DP (RS485 bus) up to 12 Mbit/s The
current configuration is indicated on the side label of the FNL.
1
2
3
4
5
Illustration1: FNL DP
1
RS232 service interface [}16]
2
Ethernet socket 10/100 RJ45 [}12]
3
24V supply voltage [}11]
4
LEDs [}17]
5
PROFIBUS socket RS485 [}13]
