Kurth Electronic TP09D - Insert; Replace Battery

© Kurth Electronic GmbH, All Rights Reserved
14
F1 F2 F3 F4
LNR MR
CID RCL
1 2 ABC 3 DEF
4 GHI 5 JKL 6 MNO
7 PRS 8 TUV 9 WXY
0 QZ #
FLASH
on Hook off Hook
ON
OFF
TP09D
9V
www.kurthelectronic.com - Made in GERMANY
SPKR
ON-OFF
Vol
+
Vol
-
Insert / replace battery
Open the battery compartment using the four
captive screws. Make sure the polarity is correct
when inserting the battery. Use only good quality
batteries.
The TP09D is waterproof. Only the battery com-
partment and the test cord connection area are
not protected. If water has penetrated into the
TP09D, this area must be dried.
The TP09D is supplied with a
sturdy, exchangeable hook for
mounting, the position of which
can be changed. If the hook is
to be removed completely, a
cover cap for the receptacle is
included.
9 V Alkaline Battery
