Effects Mode and the Effects Editor
Configurations and Parameters
9-18
Parametric EQ, Flange, Delay, and Mixer
EditEffect|||||<>Config:Para+Fla+Dly+Mix
Frq1:0.10|FlaSrc:EQ|DlyEQSrc:EQ|||||||||
Lvl1:10dB|FlaDly:0||DlyEQIn|:9|||EQ||:9|
Frq2:10.0|LFOSpd:64|DlyFlaIn:0|||DlyR:9|
Lvl2:10dB|LFODep:98|DlyTime|:9ms|DlyL:9|
Frq3:10.8|FeedBk:10|Feedback:90%|FlaR:9|
Lvl3:10dB||||||||||||||||||||||||FlaL:9|
Name|||Save|||Delete|Dump|||||||||||||||
PARAMETER RANGE OF VALUES
BAND 1 FREQUENCY 100 Hz to 12.60 KHz
BAND 1 LEVEL ±12 dB
BAND 2—3 FREQUENCY 0.1 to 12.80 KHz
BAND 2—3 LEVEL ±12 dB
FLANGE SOURCE EQ, Dry
FLANGE DELAY 0 to 10 milliseconds
LFO SPEED 0 to 65
LFO DEPTH 0 to 99
FLANGE FEEDBACK 0 to 99%
DELAY EQ SOURCE EQ, Dry
DELAY EQ IN 0 to 10
DELAY FLANGE IN 0 to 10
DELAY TIME 0 to 1500 milliseconds
DELAY FEEDBACK 0 to 99%
DRY LEVEL 0 to 10
EQ LEVEL 0 to 10
DELAY LEVEL RIGHT—LEFT 0 to 10
FLANGE LEVEL RIGHT—LEFT 0 to 10
