Kwikset SMARTCODE 9260CNT26SMTRBP - Page 10

10
A
38 mm
Install the exterior assembly
3.1
[OUTSIDE]
Route cable under the latch.If your door hole is 1-1/2” (38mm),
remove the adapter ring, and discard it.
Make sure bolt
is RETRACTED
