Kwikset SMARTCODE User Manual

15
Add a User Code and install cover
5
Secure the interior cover
onto the interior assembly.
Bolt will extend and retract to learn
the orientation of the door.
Keypad will indicate success or failure.
Green: Door handing was successful.
Red: Door handing was unsuccessful.
Make sure the interior and batteries
are correctly intalled.
[OUTSIDE]
Add a User Code per
instructions on page 19.
After the first User Code is
created, the latch bolt will
automatically retract and
extend to learn the locking and
unlocking direction of the door.

Kwikset SMARTCODE Specifications

General

Keypad	Yes
Keyless Entry	Yes
SmartKey Security	Yes
Battery	4 AA Batteries
Re-key Technology	SmartKey
Auto-Lock	Yes (programmable)
Finish Options	Satin Nickel, Venetian Bronze, Polished Brass
Power Source	Battery
Connectivity	Z-Wave
User Codes	Up to 30
Keyway	KW1
Backset	2-3/8" or 2-3/4"
Voice Control	Yes (via Z-Wave or Zigbee integration with compatible systems like Alexa or Google Assistant)
