KYMCO DINK 125 Service Manual

15. REAR BRAKE/REAR FORK/REAR
WHEEL/REAR SHOCK ABSORBER
15-13
DINK 50/125
Remove the screw (6) and brake light switch.
INSTALLATION
Install the brake light switch and tighten the
screw to the specified torque.
Torque: 1 N•m (0.1 kgf•m, 0.7 lbf•ft)
Align the pin on the master cylinder holder
with the hole on the handlebar.
Install the rear master cylinder and holder
with the “UP” mark facing up.
Install the bolts and tighten the upper bolt
first then tighten the lower bolt to the
specified torque.
Torque: 12 N•m (1.2 kgf•m, 9 lbf•ft)

KYMCO DINK 125 Specifications

General

Displacement	124.6 cc
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Front Tire	120/70-12
Rear Tire	130/70-12
Width	730 mm
Seat Height	780 mm
Cooling System	Air-cooled
Transmission	Automatic CVT
Starter	Electric
