1. GENERAL INFORMATION
1-6
Check if there is any loose wire.
Before connecting a terminal, check for
damaged terminal cover or loose negative
terminal.
Check the double connector cover for proper
coverage and installation.
Insert the terminal completely.
Check the terminal cover for proper coverage.
Do not make the terminal cover opening face up.
Secure wire harnesses to the frame with their
respective wire bands at the designated locations.
Tighten the bands so that only the insulated
surfaces contact the wire harnesses.
After clamping, check each wire to make sure it is
secure.
