KYMCO PEOPLE 150 User Manual

2. FRAME COVERS/EXHAUST MUFFLER
2-4
PEOPL E 12 5/150
FRAME COVERS
(1) REAR HAND GRIP REMOVAL
Remove the three bolts attaching the rear hand
grip.
Remove the rear hand grip.
(2) MET-IN BOX REMOVAL
Remove the three bolts and two nuts
attaching the met-in box.
Remove the met-in box.
(3) REAR FENDER REMOVAL
Remove the screw on each side of the rear
fender.
Remove (3-1) the two nuts attaching the rear
fender.
Remove the rear fender.
Remove (3-2) the license light wire connector.
(4) UNDER COVERS REMOVAL
Remove the frame center cover screws.
Remove the two screws attaching the part of
the frame body cover.
Remove (4-2) taillight rear turn signal light
wire connector.
(5) BOTTOM COVER REMOVAL
Remove the one bolt attaching each side of the
bottom protector cover.
Remove the bolt on site stand.
(6) FLOOP BOARD REMOVAL
Remove the two bolts attaching the rear floor
board.
Remove (6-1) the four bolts attaching the floor
board.
Remove the six screws attaching the floor
board.
Remove the floor board.
(7) FRONT COVER REMOVAL
Remove the bolt on the front of the front
cover.
Remove the front cover.
www.PlanDeGraissage.org

KYMCO PEOPLE 150 Specifications

General

Ignition	CDI
Front Suspension	Telescopic Fork
Front Brake	Disc
Rear Brake	Drum
Fuel Capacity	7.5 Liters
Wheelbase	1380 mm
Cooling System	Air Cooled
Starter	Electric
Transmission	CVT
