5. FUEL SYSTEM
5-11
PEOPL E 12 5/150
FUEL TANK
REMOVAL
Remove the frame body cover.
Disconnect the fuel unit wire connector.
Disconnect the fuel tube and vacuum tube at
the auto fuel valve.
Remove the fuel tank frame mounting bolts
and fuel tank frame.
Remove the four fuel tank mounting bolts and
fuel tank.
INSTALLATION
Install the fuel tank in the reverse order of
removal.
FUEL UNIT
REMOVAL
Disconnect the fuel unit wire connector.
Removal the three bolts on the fuel unit.
Fuel Unit Wire Connector
Fuel Tank
Auto Fuel Valve
Vacuum Tube
Refer to Section 17 for the fuel unit
inspection.
＊
Do not bend the fuel unit float arm;
otherwise, the fuel unit metering values
will be incorrect.
＊
Bolt
