12. FRONT WHEEL/SUSPENSION/STEERING
12-6
VENOX250/250i
THROTTLE PIPE INSTALLATION
Clean the handlebar surface and install the
throttle pipe. Check the throttle grip for
proper operation.
Connect the throttle cable to the throttle grip.
Apply grease to the throttle cable.
Install the throttle housing by aligning the
pin on the housing with the punch hole in
the handlebar. Then, tighten the two screws.
FRONT WHEEL
REMOVAL
Place a jack or other adjustable support
under the engine to raise the front wheel off
the ground.
Remove the speedometer cable set screw
and disconnect the speedometer cable.
Remove the four bolts from the right and
left front fork.
Remove the front axle bolt and pull out the
axle.
Remove the front wheel.
Throttle Cable
S
p
eedometer Cable
Speedometer Cable Set Screw
Axle
Bolt
Bolts

KYMCO Venox 250 Specifications

General

Engine Type	V-twin, 4-stroke
Displacement	249 cc
Cooling System	Liquid-cooled
Fuel System	Carburetor
Transmission	5-speed
Front Suspension	Telescopic fork
Rear Suspension	Dual Shocks
Front Brake	Single Disc
Rear Brake	Drum
Fuel Capacity	14 liters
