Kyocera ECOSYS M3540idn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6-1
1-3-56
Codes Description Corrective Action
08 Black band is not detected (DP main scan-
ning direction far end)
1. Check the attachment position of
DP.
2. Check a lighting of the lamp or
replace.
3. Check the back and front of an
adjustment original.
09 Black band is not detected (DP main scan-
ning direction near end)
0a Black band is not detected (DP auxiliary
scanning direction leading edge)
0b Black band is not detected (DP auxiliary
scanning direction leading edge original
check)
0c Black band is not detected (DP auxiliary
scanning direction trailing edge)
0d White band is not detected (DP auxiliary
scanning direction trailing edge)
0e DMA time out Turn the power supply OFF/ON and
performed again.
0f Auxiliary scanning direction magnification
error
1. Turn the power supply OFF/ON
and performed again.
2. Adjust the below items in manual
operation.
(U065 to U067, U070 to U072)
10 Auxiliary scanning direction leading edge
error
11 Auxiliary scanning direction trailing edge
error
12 DP uxiliary scanning direction skew error
13 Maintenance request error Turn the power supply OFF/ON and
performed again.
14 Main scanning direction center line error 1. Turn the power supply OFF/ON
and performed again.
Adjust the below items in manual
operation.
(U065 to U067, U070 to U072)
15 DP main scanning direction skew error
16 Main scanning direction magnification error
17 Service call error Turn the power supply OFF/ON and
performed again.
18 DP paper misfeed error Set the original correctly and per-
form again.
19 PWB replacement error -
1a Original error 1. Clean the contact glass and slit
glass.
2. Exchange the adjustment origi-
nal.
1b Input gamma adjustment original error Set the original correctly and per-
form again.
1c Matrix adjustment original error
1d Original for the white reference compensa-
tion coefficient error

Kyocera ECOSYS M3540idn Specifications

General

Secure printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	9 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Scan to	E-mail, FTP, SMB, USB
Scan drivers	TWAIN, WIA
Scanner type	ADF scanner
Grayscale levels	256
Maximum scan area	Legal (216 x 356) mm
Scan speed (color)	30 ppm
Image formats supported	JPG, TIF
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	256 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	3 sec/page
Digital sender	-
Printing colors	Black
Maximum duty cycle	150000 pages per month
Number of print cartridges	1
Page description languages	Epson LQ, IBM ProPrinter, Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Processor model	465S
Processor family	PowerPC
Card reader integrated	No
Maximum internal memory	2048 MB
Sound power level (standby)	27.3 dB
Sound pressure level (copying)	51.5 dB
Sound pressure level (quiet mode)	48.6 dB
Paper input type	Paper tray
Total input capacity	600 sheets
Total output capacity	- sheets
Maximum input capacity	2600 sheets
Total number of input trays	2
Maximum number of input trays	6
Multi-Purpose tray input capacity	100 sheets
Auto document feeder (ADF) input capacity	75 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Paper tray media types	Envelopes, Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Auto Document Feeder (ADF) media weight	50 - 120 g/m²
Control type	Touch
Product color	Black, White
Display diagonal	7 \
Market positioning	Business
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	62 W
Power consumption (PowerSave)	2.4 W
Power consumption (average operating)	685 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TUV/GS, CE
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	455 mm
Width	475 mm
Height	575 mm
