Kyocera ECOSYS M3540idn

To Next Page

To Previous Page

2NM/2NX/2NY/2NZ/2P0/2P6

1-1-8

(3) Option

Figure 1-1-4

6 7

1. Card Reader

2. Cassette 2

3. Cassette 3

4. Cassette 4

5. Cassette 5

6. Rear Tray

7. Eject Paper Stopper
