Kyocera ECOSYS M5526cdn User Manual

3-10
Preparation before Use > Preparation for Sending a Document to a Shared Folder in a PC
Preparation for Sending a Document to a
Shared Folder in a PC
Check the information that needs to be set on the machine and create a folder to receive the document on your
computer. Screens of Windows 8.1 are used in the following explanation. The details of the screens will vary in other
versions of Windows.
Making a note of the computer name and full
computer name
Check the name of the computer name and full computer name.
1
Display the screen.
In Windows 8.1, right-click [PC] in the Start screen and select [Properties]. Or, right-click the
Window icon and select [System].
In Windows 8, select the desktop in the Start screen, right-click [Computer] from [Libraries],
and then select [Properties].
2
Check the computer name.
Check the computer name and full computer name.
Screen example:
Computer name: PC001
Full computer name: PC001.abcdnet.com
Windows XP:
If the full computer name does not have a dot (.), the full computer name and the computer
name are the same.
If the full computer name has a dot (.), the text string in front of the dot (.) in the full computer
name is the computer name.
Example: PC001.abcdnet.com
PC001 is the computer name
PC001.abcdnet.com is the full computer name
After checking the computer name, click the [Close] button to close the
"System Properties" screen.
In Windows XP, after checking the computer name, click the [Cancel] button to close the
"System Properties" screen.
NOTE
Log on to Windows with administrator privileges.
NOTE
In Windows XP, right-click [My Computer] and select [Properties]. The [System
Properties] dialog box appears. Click the [Computer Name] tab in the window that
appears.
In Windows 7, from [Start] button on the Windows, select [Computer] and then [System
Properties].
In Windows 10, right-click [Start] button on the Windows and select [System].

Kyocera ECOSYS M5526cdn Specifications

General

N-up printing	2, 4, 6, 8, 9, 16, 25
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Economical printing	Yes
Duplex printing mode	Auto
Time to first page (black, normal)	9.5 s
Time to first page (color, normal)	10.5 s
Print margins (top, bottom, right, left)	4.2 mm
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	13 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	999 copies
N-in-1 copy function (N=)	2, 4
Time to first copy (black, normal)	8 s
Time to first copy (color, normal)	10 s
Copy speed (black, normal quality, A4)	26 cpm
Scan to	E-mail, FTP, SMB, TWAIN, USB, WIA
Scan drivers	TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Grayscale levels	256
Scan speed (black)	30 ppm
Scan speed (color)	23 ppm
Image formats supported	JPEG, MMR, TIFF
Duplex scan speed (black)	24 ppm
Duplex scan speed (color)	16 ppm
Document formats supported	PDF, XPS
Faxing	Mono faxing
Fax memory	100 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax resolution (black)	400 x 400 DPI
Fax transmission speed	3 sec/page
Printing colors	Black, Cyan, Magenta, Yellow
Duplex functions	Copy, Fax, Print, Scan
Maximum duty cycle	50000 pages per month
Recommended duty cycle	500 - 2000 pages per month
Replacement cartridges	TK-5240K, TK-5240C, TK-5240M, TK-5240Y
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PostScript 3
Scan media weight	50 - 160 g/m²
Custom media width	70 - 216 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 120 g/m²
Media thickness (min)	0.11 mm
Paper tray media types	Letterhead, Plain paper, Pre-Printed
Paper tray media weight	60 - 163 g/m²
Non-ISO print media sizes	Legal (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Labels, Legal, Letter, Letterhead, Plain paper, Recycled paper, Thick paper, Thin paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Memory slots	1
Processor family	ARM Cortex-A9
Compatible memory cards	SD, SDHC
Maximum internal memory	1536 MB
Sound pressure level (copying)	49 dB
Sound pressure level (standby)	30 dB
Sound pressure level (quiet mode)	44 dB
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Market positioning	Home & office
Wi-Fi	No
Email protocols	POP3, SMTP
Cabling technology	10/100/1000Base-T(X)
Security algorithms	3DES, AES, DES, HTTPS, IPPS, IPSec, SHA-1, SHA-2, SNMPv3, SSL/TLS, TLS
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print, Mopria Print Service
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	2
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1090 W
Power consumption (off)	0.2 W
Power consumption (ready)	41 W
Power consumption (sleep)	1 W
Power consumption (average operating)	375 W
Energy Star Typical Electricity Consumption (TEC)	1.024 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Certification	TÜV/GS, CE, ISO 9001, ISO 14001
Paper input type	Cassette, Paper tray
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Multi-Purpose tray input capacity	50 sheets
Cables included	AC
Included cartridge capacity (black)	1200 pages
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, REACH, RoHS, EPEAT Silver, ENERGY STAR
Package depth	567 mm
Package width	592 mm
Package height	637 mm
Package weight	33000 g
Operating altitude	0 - 3500 m
Non-operating altitude	0.6 - 15000 m
Storage temperature (T-T)	-20 - 40 °C
Operating temperature (T-T)	10 - 32.5 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Harmonized System (HS) code	84433100

Weight and Dimensions

Depth	429 mm
Width	417 mm
Height	495 mm
