Kyocera ECOSYS M5526cdw

To Next Page

To Previous Page

2-5

Installing and Setting up the Machine > Part Names (Connectors/Interior)

12 Toner Container (Yellow)

13 Toner Container (Cyan)

14 Toner Container (Magenta)

15 Toner Container (Black)

16 Toner Container Lock Lever

1213 1415
