Kyocera ECOSYS P2035d User Manual

Machine Parts 1-5
Indicators
There are six indicators located on the top right of the printer. The
indicators are used to identify the status of the printer at any time. To
identify the printer status, check the indicators on the printer and then
refer to the table below.
Indicator Status Meaning
Ready (Green) Lit
Indicates online status (printing is possible).
Fast Flashing
Offline status. You cannot print, but the printer can receive data.
Slow Flashing
The printer is in sleep mode.
Off
The printer has stopped because an error occurred.
Data (Green) Lit
The printer is processing data or is accessing to memory.
Fast Flashing
The printer is receiving data.
Off
The printer is not processing data.
Jam (Amber) Lit
A paper jam has occurred or the cassette is not inserted properly.
Off
The printer status is normal.
Paper (Amber) Lit
The paper has run out when printing.
Fast Flashing
The specified cassette or paper feeder has no paper at Ready
status. The cassette is not inserted properly.
Off
The printer status is normal.
Attention (Amber) Lit
An error has occurred because the top printer cover is open.
While an optional paper feeder (PF-100) is installed and the
feeder is selected as a paper source, the paper cassette of the
main unit (CASS1) is not installed correctly.
Fast Flashing
The warning status other than Jam, Toner, Paper, and
Attention.
Off
The printer status is normal.
Toner (Amber) Lit
The printer has stopped because the toner is exhausted.
Fast Flashing
The toner is running low.
Off
The printer status is normal.
Note For other combinations of the six indicators, call for service.
Status Monitor (software bundled with the KX Driver) will provide
more detailed information about the printer status.

Kyocera ECOSYS P2035d Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	1800 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	6 s
Print speed (black, normal quality, A4/US Letter)	35 ppm
Printing colors	Black
Maximum duty cycle	20000 pages per month
Number of print cartridges	1
Page description languages	Diablo 630, Epson LQ, IBM ProPrinter, PCL 5c, PCL 6, PCL XL, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	300 sheets
Total output capacity	- sheets
Maximum input capacity	550 sheets
Total number of input trays	2
Maximum number of input trays	3
Multi-Purpose tray input capacity	50 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	148 - 356 mm
Duplex media weight	60 - 105 g/m²
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Mobile printing technologies	Not supported
Standard interfaces	USB 2.0
Optional connectivity	Wireless LAN
Processor family	PowerPC
Maximum internal memory	544 MB
Sound power level (standby)	30.7 dB
Sound pressure level (printing)	53.3 dB
Sound pressure level (quiet mode)	49.6 dB
Display	LED
Certification	TÜV/GS, CE
Product color	Black, White
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	7.1 W
Power consumption (printing)	535 W
Power consumption (PowerSave)	2.6 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	393 mm
Width	375 mm
Height	250 mm
