Kyocera ECOSYS P6030cdn User Manual

6-38 Using the Operation Panel
Auto Cass. Change (Auto Cassette Change setting)
You can select the following actions when the paper runs out in the paper
source while printing. By default, this feature is On.
1 Press  while Print Settings > is displayed.
2 Press  or  repeatedly until >Auto Cass. Change appears.
3 To change the current paper feed source, press [OK]. A blinking
question mark (?) appears.
4 Select On or Off using  or .
5 Press [OK].
6 Press [MENU]. The display returns to Ready.
Paper Feed Mode (Setting the paper feed source)
This mode specifies how the paper should be fed once the paper feed
source and paper type have been chosen. If Auto is selected, the printer
searches for a paper feed source that matches the paper size and type,
and paper is then delivered from that source. If Fixed is selected and
there is no matching paper feed source, handling proceeds as specified
by Paper Mismatch for Error Handling. For details on paper
feeding when Fixed is selected, refer to Paper Mismatch (Detection
settings for paper size/type errors when the paper source is fixed) on
page 6-68. The default setting is Auto. To change the settings, follow the
steps described below.
1 Press  while Print Settings > is displayed.
2 Press  or  repeatedly until >Paper Feed Mode appears.
3 Press [OK]. A blinking question mark (?) appears.
4 Press  or  until Auto or Fixed appears.
5 Press [OK].
6 Press [MENU]. The display returns to Ready.
Off The printer displays Load Cassette # (# is a cassette
number) or Load MP Tray, and stops printing.
Load the paper according to the paper source displayed to
resume printing.
To print from the other paper cassette, press
 or  to
display Use alternative?, press
 or  to select the
desired paper source, and then press [GO].
On The printer continues printing automatically when the other
paper cassette contains the same paper as the currently-
used paper cassette.
>Auto Cass. Change
? On
Note You can also configure the Auto Cassette Change in the
Command Center RX. Access to the Command Center RX, and
then go to Basic > Defaults > Device Defaults page. For more
information on access to the Command Center RX, refer to the
Command Center RX User Guide.
>Paper Feed Mode
? Auto

Kyocera ECOSYS P6030cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	100000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2150 sheets
Total number of input trays	2
Maximum number of input trays	5
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	34.4 dB
Sound pressure level (printing)	52.5 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	76 W
Power consumption (printing)	529 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	480 mm
