Kyocera ECOSYS P6030cdn User Manual

Using the Operation Panel 6-37
Print Settings
These settings specify printing parameters such as the print quality used
for printing (Normal or Fine), the gloss mode (Low or High), the number
of copies, reduced printing and the page orientation.
The options available in Print Settings are as follows:
• Paper Source (Selecting the paper feed source)
• Auto Cass. Change (Auto Cassette Change setting)
• Paper Feed Mode (Setting the paper feed source)
• Duplex (Duplex printing)
• Override A4/LT (Overriding difference between A4 and Letter)
• Emulation (Setting the emulation)
• Color Mode (Selecting color or Black & White printing)
• Print Quality (Setting print quality)
• Page Set (Setting pagination)
• Job Name (The Job Name display settings)
1 Press [MENU].
2 Press  or  repeatedly until Print Settings > appears.
Paper Source (Selecting the paper feed source)
You can select the paper source, from which the printer feeds paper as
the default. If an optional paper feeder(s) is installed, it is also available
for the default paper source.
1 Press  while Print Settings > is displayed.
2 Press  or  repeatedly until >Paper Source appears.
3 To change the current paper feed source, press [OK]. A blinking
question mark (?) appears.
4 Press  or  to display the desired paper feed source. The message
display toggles through the following paper feed sources, depending
on the installed optional paper feeders (from the top most paper
cassette to the bottom paper cassette):
MP tray
Cassette 1
Cassette 2
Cassette 3
Cassette 4
Cassettes 2, 3 and 4 are available for selection when the optional
paper feeders are installed.
5 Press [OK].
6 Press [MENU]. The display returns to Ready.
Print Settings >
>Paper Source
? Cassette 1

Kyocera ECOSYS P6030cdn Specifications

General

Color	Yes
Print technology	Laser
Maximum resolution	600 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	30 ppm
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	100000 pages per month
Number of print cartridges	4
Page description languages	Microsoft XPS, PCL 5c, PCL 6, PCL XL, PDF 1.7, PostScript 3
Paper input type	Cassette, Paper tray
Total input capacity	650 sheets
Total output capacity	- sheets
Maximum input capacity	2150 sheets
Total number of input trays	2
Maximum number of input trays	5
Multi-Purpose tray input capacity	150 sheets
Custom media width	70 - 216 mm
Maximum print size	216 x 356 mm
Custom media length	138 - 356 mm
Paper tray media types	Plain paper
Paper tray media weight	60 - 120 g/m²
Non-ISO print media sizes	Folio (media size), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 220 g/m²
Wi-Fi	No
Mobile printing technologies	-
Standard interfaces	Ethernet, USB 2.0
Optional connectivity	Wireless LAN
Processor model	465S
Processor family	PowerPC
Maximum internal memory	1536 MB
Sound power level (standby)	34.4 dB
Sound pressure level (printing)	52.5 dB
Display	LCD
Certification	TÜV/GS, CE
Product color	Black, White
Display number of lines	2 lines
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0 W
Power consumption (standby)	76 W
Power consumption (printing)	529 W
Power consumption (PowerSave)	4 W
Mac operating systems supported	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Sustainability certificates	Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	518 mm
Width	345 mm
Height	480 mm
