NOTES
1. Indicate parts number and machine model when placing an order.
e.g. Parts Number Parts Name Machine Model Frequency Quantity
302GZ05010
COVER UPPER OPERATION 40 (40ppm)
FS-9130DN
50/60Hz 1
302G105010
COVER UPPER OPERATION 50 (50ppm)
FS-9530DN
50/60Hz 1
2. Service calls and freight will be charged separately.
3. Symbols in the "Parts Number" column.
• Parts with "•" are component parts or sub-assemblies of the assembly appearing immediately above them.
e.g. Parts Number Parts Name Parts Number Parts Name
302G193082 PARTS LEFT COVER MIDDLE ASSY
2BL04550 LEVER L COVER LOCK M
2BL04560 SPRING L COVER LOCK
• Parts with "••" are component parts or sub-assembly with "•" appearing immediately above them.
e.g. Parts Number Parts Name Parts Number Parts Name
•302GR93182 PARTS REAR GUIDE FUSER UNIT ••2BL16290 CUT WASHER 3
••2BL21330 PULLEY FEED SHIFT
• Parts with "" indicate the spare parts and the parts without "" can not be supplied.
4.
Items indicated in Description column as (OPTION) are supply parts and should be ordered through your Regional Office.
