Low Frequency
Output Using
OUTPUT Terminal
0-10V
0-50V
0-250V
0-1000V
Refer to frequency
characteristic chart
Low Frequency
Output (dB)
(4 ranges)
10V AC
−
10 - +22dB
50V AC +4 - +36dB
250V AC +18 - +50dB
1000V AC +30 - +62dB
(0 dB = 0.775V(1mW)
across a 600Ω line)
Refer to frequency
characteristic chart
DC Current Amplication
Factor (h
FE
) (1 range)
h
FE
: 0-1000 (atΩ× 10 range)
±3% of scale length
Dimensions: 100 (W) x 150 (L) x 47 (D)mm
Weight: Approx. 330g
Accessories: Test Leads (Model 7066A) - 1 set
F250V 0.5A fuse - 2 pcs. (including one spare fuse
also installed into the housing case)
1.5V Battery Type R-6P, SUM-3, AA or equivalent -
2 pcs.
(Installed into the instrument)
9V Battery Type 6F22, 006P PP3, or equivallent
- 1 pce (installed into the instrument)
Instruction Manual - 1 copy
