For amplifying 4 112XT in parallel, the recommended amplifier specifications are:
* LOW Amplifier Output Power: 2320 W into 2 ohms
* HIGH Amplifier Output Power: 2160 W into 2 ohms
Based on these specifications, recommended L-ACOUSTICS LA power amplifier specifications and
MLS switch settings are summarized in Tables 2 and 3. In these tables, boldface settings indicate a
good power match based on the recommended power amplifier specification.
Table 2: Recommended power amplification and MLS switch settings for 112XT low section
112XT LOW SECTION AMPLIFIER OUTPUT POWER
REC'D POWER (MLS SETTING)
LOAD POWER LA 17a LA 24a LA 48a
(ohms) (W)
2 2320 do not use do not use
2400
(-2 dB)
2.7 1740 1080 1635
2130
(0 dB) (0 dB)
(-2 dB)
4 1160 840
1300 1600
(0 dB)
(-2 dB) (-2 dB)
8 580 430
700 820
(0 dB)
(-2 dB) (-2 dB)
Table 3: Recommended power amplification and MLS switch settings for 112XT high section
112XT HI SECTION AMPLIFIER OUTPUT POWER
REC'D POWER (MLS SETTING)
LOAD REC'D LA 17a LA 24a LA 48a
(ohms) POWER
2 2160 do not use do not use 2000
(-4 dB)
2.7 1600 1080
1635 1665
(0 dB)
(0 dB) (-4 dB)
4 1080 840
1300
1000
(0 dB)
(-2 dB)
(-4 dB)
8 540 430
700
520
(0 dB)
(-2 dB)
(-4 dB)
L-ACOUSTICS LA amplifier MLS switch settings for powering the 112XT are summarized in Table 4
and Figure 4 shows the location of MLS switches on the LA24a and LA48a rear panel.
