The XT range components are compatible with standard L-ACOUSTICS accessories. These accessories include the
loudspeaker cables SP.7, SP10, and SP25 with respective lengths of 0.7m (2.3ft), 10m (32.8ft), and 25m (82ft). Each
cable is 4 conductor cable with 4mm
2
conductor cross-section (13 SWG, 11 AWG) and features two NEUTRIK
®
NL4FC Speakon
®
connectors.
The XT system is driven and powered exclusively by the L-ACOUSTICS
®
LA4 amplified controller. This ensures
intelligent protection, filtering, and equalization of the enclosures. 4 channels of amplification are provided along with
the OEM factory preset library, ensuring the optimization and performance of the system within limitations of the
recommended configurations.
Each system design configuration should be first modeled and studied using the L-ACOUSTICS
®
SOUNDVISION
application software. The software predictions are based on the preset parameters stored in the amplified controllers.
Several amplified controllers can be interconnected and monitored through the proprietary L-ACOUSTICS
®
L-NET
network using the L-ACOUSTICS
®
LA NETWORK MANAGER application software.
A detailed description on the use of the LA4 amplified controller, SOUNDVISION and LA NETWORK MANAGER
application softwares are beyond the scope of this manual. Please refer to the appropriate documentation, also available
on the L-ACOUSTICS internet website
@
www.l-acoustics.com
.
