L-Acoustics ARCS II Rigging Manual

ARCS
®
II SYSTEM
rigging manual
VERSION 1.1
ARCSII_RM_EN_1-1
w w w . l - a c o u s t i c s . c om
14
 PROCEDURE D: Installing the ARCBUMP
a
A shackle is being removed from an ARCOUPL bar
b
The ARCOUPL bars are being slid in the rigging rails
A shackle (Ø12mm) being reinstalled along with a safety sling

The array secured with safety steels front and back)

A shackle (Ø18mm) being secured on the ARCBUMP
END
A 3-ARCS
®
II vertical array ready to be flown (2-point)
