ARCSII_RM_EN_1.1
w w w . l - a c o u s t i c s . c o m
5
1 RIGGING SYSTEM
The system approach developed by L-ACOUSTICS
®
consists in providing packaged solutions for loudspeaker system in
order to guarantee the highest and most predictable level of performance at any step: modeling, installation, and
operation. An L-ACOUSTICS
®
loudspeaker system is the set of components available to form any loudspeaker system
based on one of the full-range loudspeaker enclosure afforded by L-ACOUSTICS
®
. It includes enclosures, rigging
accessories, loudspeaker cables, amplified controllers, and software applications.
The main components involved in the rigging process of the ARCS
®
II SYSTEM are the following:
1.1 Loudspeaker enclosures
Full range 2-way active enclosure, arrayable in a constant curvature line,
provided with 2 ARCOUPL bars and 4 D-shackles Ø12mm
High power subwoofer enclosure
Bar for flying a horizontal array of 2 or 4 ARCS
®
II,
provided with1 D-schackle Ø18mm, 2 pierced bolts, 2 nuts and 2 pins
Bar for flying a horizontal array of 1, 3, 5 or 6 ARCS
®
II enclosures,
provided with2 D-schackle Ø18mm and 2 D-schackle Ø22mm,
(to be used with 2 BUMP3)
Frame for flying a vertical array of up to 4 ARCS
®
II,
provided with 2 ARCOUPL bars, 4 D-shackles Ø12mm, 2 D-schackle Ø18mm,
6 safety slings 42mm and 6 safety slings 155mm.
Proprietary 3D acoustical and mechanical modeling software
Removable front dolly board for moving the enclosure and protecting the enclosure front grill
during transportation and storage
Protective cover for transportation and storage
Other ARCS
®
II SYSTEM components
All the other components of the system are presented in the ARCS
®
II SYSTEM user manual, document
intended to describe the operating modes and the loudspeaker connection.
