L-ACOUSTICS MTD Manual V1.2 11/30/2004 47
Table 16: Nominal floor monitor distance (to performer) and separation versus performer height
MTD108a (short-throw: 22.5 angle wrt vertical, 100 deg coverage)
PERFORMER HEIGHT Performer <-> Monitor Monitor <-> Monitor
(cm) (ft / in) (cm) (ft / in) (cm) (ft / in)
160 5 ft 3 in 66 2 ft 2 in 79 2 ft 7 in
165 5 ft 5 in 68 2 ft 3 in 81 2 ft 8 in
170 5 ft 7 in 70 2 ft 4 in 84 2 ft 9 in
175 5 ft 9 in 72 2 ft 5 in 86 2 ft 10 in
180 5 ft 11 in 75 2 ft 5 in 89 2 ft 11 in
185 6 ft 1 in 77 2 ft 6 in 91 2 ft 12 in
190 6 ft 3 in 79 2 ft 7 in 94 3 ft 1 in
MTD108a (long-throw: 45 angle wrt vertical, 100 deg coverage)
PERFORMER HEIGHT Performer <-> Monitor Monitor <-> Monitor
(cm) (ft / in) (cm) (ft / in) (cm) (ft / in)
160 5 ft 3 in 160 5 ft 3 in 191 6 ft 3 in
165 5 ft 5 in 165 5 ft 5 in 197 6 ft 5 in
170 5 ft 7 in 170 5 ft 7 in 203 6 ft 8 in
175 5 ft 9 in 175 5 ft 9 in 209 6 ft 10 in
180 5 ft 11 in 180 5 ft 11 in 215 7 ft 0 in
185 6 ft 1 in 185 6 ft 1 in 220 7 ft 3 in
190 6 ft 3 in 190 6 ft 3 in 226 7 ft 5 in
MTD112b (45 angle wrt vertical, 85 deg coverage)
PERFORMER HEIGHT Performer <-> Monitor Monitor <-> Monitor
(cm) (ft / in) (cm) (ft / in) (cm) (ft / in)
160 5 ft 3 in 160 5 ft 3 in 147 4 ft 10 in
165 5 ft 5 in 165 5 ft 5 in 151 4 ft 12 in
170 5 ft 7 in 170 5 ft 7 in 156 5 ft 1 in
175 5 ft 9 in 175 5 ft 9 in 160 5 ft 3 in
180 5 ft 11 in 180 5 ft 11 in 165 5 ft 5 in
185 6 ft 1 in 185 6 ft 1 in 170 5 ft 7 in
190 6 ft 3 in 190 6 ft 3 in 174 5 ft 9 in
MTD115b (41 angle wrt vertical, 85 deg coverage)
PERFORMER HEIGHT Performer <-> Monitor Monitor <-> Monitor
(cm) (ft / in) (cm) (ft / in) (cm) (ft / in)
160 5 ft 3 in 139 4 ft 7 in 127 4 ft 2 in
165 5 ft 5 in 143 4 ft 8 in 131 4 ft 4 in
170 5 ft 7 in 148 4 ft 10 in 135 4 ft 5 in
175 5 ft 9 in 152 4 ft 12 in 139 4 ft 7 in
180 5 ft 11 in 156 5 ft 2 in 143 4 ft 8 in
185 6 ft 1 in 161 5 ft 3 in 147 4 ft 10 in
190 6 ft 3 in 165 5 ft 5 in 151 4 ft 12 in
