System components
System components
Loudspeaker enclosures
X12 2-way passive coaxial enclosure: 12'' LF + 3'' HF diaphragm
SB15m High power compact subwoofer : 1 x 15''
SB18 High power compact subwoofer: 1 x 18''
SB18 IIi High power compact subwoofer: 1 x 18" (installation version)
KS21 High power compact subwoofer: 1x21''
KS21i High power compact subwoofer: 1 x 21" (installation version)
Powering and driving system
LA4X / LA8 / LA12X Amplied controller with DSP, preset library and networking capabilities
Refer to the LA4X / LA8 / LA12X owner's manual for operating instructions.
Racks
LA-RAK Touring rack containing three LA8 and power, audio and network distribution
LA-RAK II AVB Touring rack containing three LA12X, LA-POWER II for power distribution, LA-PANEL II for audio
and network distribution, and two LS10 for AVB distribution
Cables
SP cables 4-point speakON loudspeaker cables (4mm² gauge)
SP cables come in four sizes: SP.7 (0.7m/2.3ft), SP5 (5m/16.4ft), SP10 (10 m/32.8ft) and
SP25 (25m/82ft)
SP-Y1 breakout cable for two passive enclosures (2.5mm² gauge) provided with a CC4FP adapter
4-point speakON to 2 × 2-point speakON
DO 8-point PA-COM loudspeaker cables (4mm² gauge)
DO cables come in three sizes: DO.7 (0.7m/2.3ft), DO10 (10m/32.8ft) and DO25
(25m/82ft)
DOSUB-LA8 breakout cable for four passive enclosures (4mm² gauge)
8-point PA-COM to 4 × 2-point speakON
Information about the connection of the enclosures to the LA amplied controllers is given in
this document.
Refer to the LA4X / LA8 / LA12X owner's manual for detailed instructions about the whole cabling scheme,
including modulation cables and network.
Rigging elements
X-UL12 Long U-bracket for X12
X-US1215 Short U-bracket for X12 and X15 HiQ
X-UTILT U-bracket wallmount for X series with tilt adjustment
X-BAR Rigging bar for 1 enclosure
EMBi Pole mount socket: 8XTi/12XTi and X series
CLAMP250 Clamp certied for 250 kg
8 X12 owner's manual (EN) version 1.0
