7.0 SPECIFICATIONS
INPUTS
MIC electronically balanced, 1.2k, XLR-F, pin 2 = hot
LINE electronically balanced, 20k, 1/4" TRS, Tip = hot
DI unbalanced, 0.5M, 1/4" jack, wired Tip = hot
OUTPUTS
Type Ground sensing, balanced impedance
XLR-M +4dBu, wired pin 2 = hot
1/4" TRS jack -10dBV, wired Tip = hot
Impedance <100
Max. output +20dBu
PERFORMANCE
THD < 0.05%, Mic input at 50dB gain
Noise Mic < -127dBu EIN, 20Hz to 20kHz
Line <-90dBu (at unity gain), 20Hz to 20kHz
DI <-80dBu (at +20dB gain), 20Hz to 20kHz
Frequency response ±0.5dB @ 20kHz
CONTROLS
Gain Mic = +6dB to +60dB, Line = -10dB to +20dB
DI = 0dB to +30dB
Clip led Lights 3dB before clipping (+18dB typical)
Phantom Power +48V
Input select Mic, Line or DI
Phase 0° or -180°
Highpass filter -12dB/Oct below 25Hz to 250Hz
NR Threshold -70dB to 0dB
NR ratio 2:1
NR Attack/Release Attack = <1mS, Release = 0.5S
Comp Threshold -30dB to +20dB
Ratio 1:1 to 20:1
Attack 5mS (fast), 20mS (slow)
Release 0.5S (fast), 2S (slow)
Equaliser LF: ±15dB, 80Hz
LMF: ±15dB, 60Hz to 2.4kHz
HMF: ±15dB, 500Hz to 20kHz
HF: ±15dB, 12kHz
Bandwidth (Q) 1/12th octave to 3 octaves
Lowpass Filter 12kHz, -6dB/octave
Output level ±20dB
Meter -20, -10, -6, -4, -2, 0, +2, +4
POWER SUPPLY
Mains voltages 230VAC, 50Hz, 6VA Europe
115VAC, 60Hz, 6VA North America
220VAC, 60Hz, 6VA ROK
Mains connector Standard IEC receptacle
MECHANICAL
Dimensions 1.75" (44mm)H x 19" (482mm)W x 6.5" (165mm)D
