SPECIFICATION
Lab.gruppen AB, Gullregnsvägen 16, SE-434 44 Kungsbacka, Sweden.
Tel. +46 300 168 23. Fax +46 300 142 46. www.labgruppen.se
1200C
MAX OUTPUT POWER
1)
16 Ω four channels
8 Ω four channels
4 Ω two channels
2)
4 Ω four channels
2 Ω two channels
2)
16 Ω bridged stereo
8 Ω bridged stereo
MLS
Switch
8
8
8
4
4
8
4
FTC
20 Hz-20 kHz
at 0.1% THD
190 W
350 W
650 W
340 W
580 W
700 W
680 W
EIA
1 kHz
at Clip (1% THD)
200 W
370 W
700 W
380 W
640 W
740 W
760 W
IHF
Peak Power
20 msburst
210 W
380 W
720 W
400 W
720 W
760 W
780 W
SPEAKER PROTECTION
Each channel is fuse protected on the positive and negative power supply rails. Electronic short-circuit protection with a progressive
characteristic. The output power is turned off at shorted output. The power amplifier can be run into short-circuits for a long time
without damage, and is open circuit and mismatch proof.
DISTORTION
THD 20 Hz-20 kHz and 1 W-240 W 4 ohms 0.07 %
THD at 1kHz and 300W 4 ohms 0.01 %
DIM 30 at 150 W 4 ohms 0.008 %
CCIF (13 and 14 kHz) at 100 W 4 ohms 0.008 %
SMPTE (60 Hz and 7 kHz) at 150 W 4 ohms 0.01 %
POWER BANDWIDTH
3)
5 Hz-110 kHz
Slew rate 60 V/µs
OUTPUT IMPEDANCE
1 kHz 0.03 ohm
HUM AND NOISE
below max power <- 105 dBA
CHANNEL SEPARATION
1 kHz 80 dB
10 kHz 70 dB
PHASE AND DELAY
Deviation from perfect delay 150 Hz-20 kHz ± 1°
Total delay input to output at 4 ohms 3.5 µs
INPUTS
Sensitivity for full output into 4 ohms 1.3 Vrms
Gain 29 dB
Impedance 20 kohms, balanced
Common mode rejection at 1 kHz 50 dB
FRONT PANEL
Gain controls (4) Channel A - B, C - D
Output displays (4) red + (4 ( 2)green LED´s Fast peak - slow release
Protect indicator (4) yellow LED´s 80° C at heatzink or > 20 kHz at full power or shorted output.
On indicators (4) green LED´s DC rail voltage for channel A, B, C and D
REAR PANEL
Input connectors (4) XLR type 3 pin female (pin 2+).
Output connectors (2) Neutric 4-pole speakon connectors (pin 1+ output, A, C)
Switches: (pin 2+ output, B, D)
Link A+B / B+C / C+D
Polarity B Reverse polarity of channel B
Polarity D Reverse polarity of channel D
Clip limiter A, B, C and D On - Off
MLS 4 or 8 ohms
POWER
Option
Operation voltage 130 V - 280 V AC 65 V -135 V AC
Minimum start voltage 190 V AC 95 V AC
Full output power 180 V - 260 V AC 90 V - 130 V AC
Peak inrush current 4.5 A
OVERALL DIMENSIONS
mm (inch) 483 (19”) W
x 88 (3.5”) H
x 335 (13.2”) D
WEIGHT
8.7 kg (19 lbs)
APPROVALS
CE Emission EN 55 103-1, E3
Immunity EN 55 103-2, E3, with S/N below 1% at normal
operation level
4)
Safety EN 60 065, class I
LAB. GRUPPEN reserve the right to alter functions or specifications without prior notice.
1) Specifications measured with 230 V regulated AC
2) Continuous power, two channels driven or peak power four chan-
nels driven. (Thermal protection may occur at high continuous power).
3) The VHF-protection turns off the channel for frequencies above 20 kHz
at full power.
4) Normal operation level 1/8 of full power or -9dB below clip point.
