Instruction Manual – 21
12. Spare Parts
Contact our Customer Service to inquire about availability
of spare parts. Pipettor model and name of the part required
should be specied. The most common parts are depicted
below.
NOTE: The replacement of the plunger requires conducting
the calibration procedure according to Section 9.
G
L
I
J*
S
C
D
F
P
G
B
M
Item Description Model Cat. No. Qty/Pk
B
Volume adjustment
knob set
All SP29327 1
C, I,
J*
Shaft with O-ring and
seal – grey
2 SP19111 1
10 SP19112 1
20 SP19113 1
100 SP19114 1
200 SP19115 1
1,000 SP19116 1
5,000 SP19118 1
10,000 SP19119 1
*Seal (J) used only in models 2, 5,000 and 10,000 µL
