of all installed components. Further a screen makes it possible to see the time, pressure and
temperature of the system in real-time. This mode of operation is described in a separate manual for
this option.
5 Operation
The touch control system is designed and developed for running the CoolSafe freeze dryers
specifically. All the build in facilities are designed to facilitate easy control of the freeze dryer and the
freeze drying process in either manual or automatic running mode.
The touch control system is based on a simple structured menu structure for easy and logical setup
and control of the freeze dryer and freeze drying process. Navigation is done using a light touch of
a finger and all the menu items have been named to facilitate an intuitive and logical approach for
the user.
6 User interface
On start up the screen below will be showing until the control system is up and running.
When the system is fully loaded and initialized the main menu will be displayed on the touch screen.
