Labomed Lx 100 - User Manual

Questions and Answers

S
Stacey WhiteAug 16, 2025
Why is the observation image hazy or unclear on my Labomed Microscope?
- L
  lopezrobertAug 17, 2025
  A hazy or unclear observation image on your Labomed Microscope can occur for several reasons: * The objective may not be fully engaged in the light path; ensure it clicks into position. * The objective, eyepiece, condenser, or specimen glasses might be dirty; clean them thoroughly. * If using an immersion objective, immersion oil may be required. Use it if needed. * Bubbles might be present in the immersion oil; remove them by agitation. * The incorrect immersion oil may be in use; use the immersion oil supplied by Labomed.
P
phansenAug 19, 2025
What to do if the LED on my Labomed Microscope does not light?
- M
  Megan DavidsonAug 19, 2025
  If the LED on your Labomed Microscope isn't lighting up, consider these potential causes: 1. The LED might not be properly mounted; attach it securely. 2. The LED could be blown; replace it. 3. The power cord may be unplugged; plug it in securely. 4. The fuse might be blown; check and replace it with a live fuse. 5. The battery could be low; charge the battery.
N
Nina RodriguezAug 22, 2025
How to fix uneven brightness in the observation field of my Labomed Lx 100?
- K
  kaylameyerAug 23, 2025
  Uneven brightness in the observation field of your Labomed Microscope can be due to: * The objective not being fully engaged in the light path; engage the objective until the nose turret clicks. * The condenser being too low; raise it to achieve maximum light. * Dirty objective, eyepiece, condenser, or window lens; clean them thoroughly.
A
aaron39Aug 26, 2025
How to remove dust or stains visible in the observation field of my Labomed Lx 100 Microscope?
- R
  Randy NewtonAug 26, 2025
  If you see dust or stains in the observation field of your Labomed Microscope, the eyepiece, condenser, window lens, or specimen glasses may be dirty. Clean them thoroughly with lens tissue and alcohol.
C
Carrie JohnstonAug 28, 2025
Why does the observation image have glare on my Labomed Microscope, and how can I fix it?
- G
  grayjeremyAug 28, 2025
  Glare in the observation image of your Labomed Microscope can be caused by: * The condenser being too low; raise it. * The condenser iris diaphragm ring being excessively closed; adjust the aperture according to the objective magnification.
S
Shelly JohnsonAug 31, 2025
What to do if the objective hits the specimen when switching to a higher magnification objective on my Labomed Microscope?
- D
  daryljacksonAug 31, 2025
  If the objective hits the specimen when switching to a higher magnification objective on your Labomed Microscope: * Ensure the specimen is correctly oriented with the cover glass on top. * Verify the cover glass thickness is 0.17mm. * Lower the stage. * Re-position the slide in the slide holder if it has slipped. * Use a slide with a thickness between 0.9 and 1.4mm.
J
Jeffrey ReedSep 3, 2025
How to fix a partially defocused image on my Labomed Lx 100 Microscope?
- D
  Danny HudsonSep 3, 2025
  If part of the image is defocused on your Labomed Microscope: * Ensure the objective is properly engaged in the light path until the nose turret clicks. * Make sure the specimen is correctly set on the stage and secured using the specimen holder.
M
Mackenzie GutierrezSep 6, 2025
Why don't the fields of view of two eyes match on my Labomed Microscope?
- M
  Mary MillerSep 6, 2025
  If the fields of view for your two eyes don't match on your Labomed Microscope, it could be due to: * The interpupillary distance not being adjusted properly; adjust IPD. * IPD compensation for the two eyes not being set; adjust it correctly. * The left and right eyepieces being of different magnification; replace one so they are identical.
T
terristaffordSep 9, 2025
What to do if the high-magnification objective touches the specimen just before focusing on my Labomed Lx 100 Microscope?
- H
  Hannah ParkerSep 9, 2025
  If the high-magnification objective touches the specimen just before coming into focus on your Labomed Microscope, the specimen may be upside down. Set the specimen correctly with the cover glass on the top.
S
Stephanie BartonSep 12, 2025
Why does the LED blow easily on my Labomed Lx 100 Microscope?
- G
  garcianatalieSep 13, 2025
  If the LED blows easily on your Labomed Microscope, it may be because the specified LED is not being used. Replace it with the specified LED.

Labomed Lx 100 Specifications

General

Type	Biological Microscope
Optical System	Finite Optical System
Eyepiece	WF 10x/18mm
Objectives	Achromatic 4x, 10x, 40x, 100x (S, Oil)
Magnification	40x to 1000x
Nosepiece	Quadruple
Focusing	Coaxial Coarse and Fine Focusing Knobs
Condenser	Abbe N.A. 1.25 with Iris Diaphragm
Illumination	LED illumination, adjustable brightness
Power Supply	110V - 240V AC, 50/60Hz
