96 Maintenance
4. Carefully remove the element by the handle, rotating it as you do so to release suction.
5. Remove and retain the yellow contamination retainer. Clean and install onto the new filter.
6. Inspect O-rings and housing for damage. Replace as necessary.
7. Moisten sealing surfaces (with oil) on the filter housing and cover plate.
8. Install element into housing, carefully locating the element onto the spigot.
9. Replace cover plate.
10. Operate hydraulic system and check for leaks.
Hydraulic Oil
Factory filled hydraulic oil is tested for cleanliness and identified by a tag attached to the hydraulic
tank.
Hydraulic oil is the lifeblood of the system. Particles in the oil will devastate any hydraulic system
overtime, therefore regular oil changes will most likely extend the life of components and equipment.
