Maintenance 115
If your unit is equipped with this option, an additional work section has been added to the main valve
bank, equipped with work port relief valves, to supply the adjustment cylinders mounted to the fork
assembly.
The work port relief valves are preset to 1500 psi and are non-adjustable.
Pressurized oil is directed from the work section to the flow dividers mounted on the fork assembly.
The flow dividers ensure the cylinders receive equal amounts of oil.
Curotto Automated Can
The Curotto Can (see Figure 3-63) is a hydraulic attachment which allows for automated residential
collection using a commercial style vehicle.
Figure 3-63
Curotto Can
Details can be found in the Curotto Can “Operations and Maintenance” and “Parts and Service”
manuals available from Labrie.
Cart Tipper
Refer to “Auxiliary Hydraulic Attachment Work Section” on page 104.
Consult OEM for further information.
Figure 3-64
Cart tipper
