Lacanche MACON - Opening and Closing the Hob

INSTALLER’S MANUAL
To remove top :
1- Remove the pan racks and burners.
2- Unscrew the screw(s) on burners (see
A
and
B
figures
1
and
2
).
3- Loosen the 2 screws (see
C
figure
3
) through the ventilation strip.
4. Lift the hob (figure
4
).
5- Wedge the hob open (see
D
figure
4
).
Retting the cooking surface
When refitting the cooking surface, it is vital to tighten the fastening screws. Failure to do so can
cause distortion of the hob top.
It may be necessary to open the hob under the following circumstances :
- Making adjustments when changing gas type.
- Adjusting thermocouples.
- Resetting the safety thermostat on the Radiant. Electric Hob
OPENING AND CLOSING THE HOB
D
C
A
B
1
2
3
4
D
1.Pull foward
2. Lift the table
Chagny - Macon (UK) - Ft 138a - GB - Rév 06 - Modifié le : 07/10/2013 12/42
