Lacanche MACON - TECHNICAL DATA; Gas Hob Technical Details

INSTALLER’S MANUAL
►MACON : TRADITIONAL GAS HOB
5 Gas Burners with simmer plate :
- 5 burners of different size and power (see hob T,
C, D table 1, appendix 0)
- Large cooking zone equipped with a simmer plate
385 x 510 mm.
- Individually controlled by a thermocouple safety
valve.
- Electric push button ignition.
►MACON : CLASSIC 5 BURNER GAS HOB
5 Gas Burners :
- 5 burners of different size and power (see hob A,
C, D table 1, appendix 0).
- Individually controlled by a thermocouple safety
valve.
- Electric push button ignition.
CHAGNY - MACON(uk) CLASSIC AND TRADITIONAL : GAS HOBS
1000
527
815
280
935
725
650
896
900
TECHNICAL DATA
385
C
C
B
D
A
500
C
C
B
D
T
385
500
Gas connection : Tube ∅ 15/21, 1/2” gas thread, on male
coupling
The height of the cooker is adjustable between 900 and 916 mm.
Electric connection, on terminal block at the rear of the appliance
►
Front body panels : Stainless steel or enamelled steel.
► Hob : Pressed stainless steel.
Chagny - Macon (UK) - Ft 138a - GB - Rév 06 - Modifié le : 07/10/2013 3/42
