1.10. Ethernet Cable
Gigabit Ethernet Cables and Connectors
The cable used to attach Gigabit Ethernet devices
is shown in Fig. 12 - Ethernet Cable Ends.
NOTE: LaCie recommends Cat 5E or
Cat 6 cables. Both support Gigabit
Ethernet.
Fig. 12 - Ethernet Cable Ends
Desktop PCs and Macs
(via Ethernet)
Ethernet Switch
5big Storage Server
(via Ethernet)
Laptops
(via Wi-Fi)
2big Quadra
(for backup)
Server
Fig. 13 - Network Configuration
