TABLE OF CONTENTS
TECHNICAL SPECIFICATIONS ................................................2
GENERAL SAFETY INSTRUCTIONS .......................................3
SPECIFIC SAFETY INSTRUCTIONS FOR TILE SAW ...............5
SAW FEATURES ........................................................................7
UNPACKING THE SAW ............................................................8
ASSEMBLY ............
.................
...................................................9
MOVING AND STORING TILE SAW .......................................11
OPERATION .............................................................................11
MAKING CUTS
........................................................................13
MAINTENANCE
.......................................................................
.......................................................................
15
TROUBLESHOOTING YOUR SAW
........................................18
ADJUSTMENTS 17
1-YEAR LIMITED WARRANTY
...............................................18
PARTS, SERVICES AND WARRANTY ASSISTANCE
...........18
REPLACEMENT PARTS
..........................................................18
2
Power supply 120V, 60Hz
Motor capacit y 13A
No-load speed 5,300 RPM
Diamond cutting wheel size 7" Dia. X 5/8" (Bore)
Maximum depth of cut at 90º 2-3/8 "
Maximum depth of cut at 45º 1-1/4"
Tilting range 22.5º and 45º
Maximum rip cut 24"
Maximum square tile of diagonal 18"
NOTICE: The manual cover illustrates the current production model. All other illustrations contained in the manual
are representative only and may not be exact depictions of the actual labeling or accessories included. They are
intended for illustrative purposes only.
TECHNICAL SPECIFICATIONS
SAVE THESE INSTRUCTIONS.
Refer to them often and use them to instruct others.
If tool is loaned to someone, also loan them these instructions.
2
