SAW FEATURES
7
The use of any accessory or attachment or performance of any operation with this tool other than
those recommended in this instruction manual may present a risk personal injury.
1. Water Tray
2. Front rail, main frame
3. Miter guide
4. Worktable
5. Motor/arm assembly
6. Water hose
7. Submersible pump (not pictured)
8. Diamond blade
9. Blade guard
10. Plunge lock knob
11. Blade stop adjustment knob
12. Bevel lock knob
13. Splash guard
14. On/Off switch (not pictured)
15. Drain plug (not pictured)
11
10
9
8
4
3
2
1
12
5
13
6
7
