laerdal MegaCode Kelly User Manual

Replace the Neck Skin, ECG/Defib studs, IM pads and Torso Skin
7
Replace the neck skin
Attach the new neck skin around the neck.
Replace the ECG and defibrillation studs
Note
There are two sizes of washers: short for the defibrillation studs (2) and long for the ECG studs (4)
1. Use spring clip pliers to loosen the studs.
2. Remove the plastic covers to access the nuts if necessary.
3. Place the covers and tighten with screws.
Note
You can also use Loctite (not provided in the kit).
4. Place the chest plate on the torso.
5. Place the foam pad inside the chest and the tubes in their housing.
Note
Make sure the tubes are on top of the foam parts.
Assemble the legs
1. Assemble the legs on the torso.
2. Tighten the legs with screws.
Replace the Intra Muscular (IM)pads
Replace the IM pads inside the shoulder, lower back and thighs.
Replace the torso skin
1. Take the new torso skin.
2. Attach it to the torso.
